LM LMA LM 3-Amp Adjustable Regulators. General Description. The LM series of adjustable 3-terminal positive voltage regulators is capable of. Nov 11, The LM is an adjustable 3-terminal positive voltage regulator capable of supplying in excess of A over an output voltage range of V to. The LM is an adjustable 3-terminal positive voltage regulator capable of supplying in excess of A over an output voltage range of V to 33V. 1. Adj 2.

Author: Grora Kim
Country: Ukraine
Language: English (Spanish)
Genre: Environment
Published (Last): 28 January 2013
Pages: 147
PDF File Size: 6.33 Mb
ePub File Size: 18.12 Mb
ISBN: 153-4-58097-859-7
Downloads: 13068
Price: Free* [*Free Regsitration Required]
Uploader: Nak

Solid tantalum capacitors can be used on the voltage output datasheett improve the ripple rejection of the voltage regulator. We have many ways to make it. An optional output capacitor can be added to improve transient response.

National Semiconductor

Leave a Reply Cancel reply. In addition, it uses internal current limiting, thermal shutdown, and safe mode.

We can set the output voltage with only two external resistors. Because it is the adjustable three terminal positive voltage regulator. As in the LM pinout above. Last update 6 January Plan to be about 3V about the desired output voltage. The LM may be boring for you. Although the surge is very short in duration, there is enough energy to damage parts of the regulator IC. You don’t want to use too high an input voltage as the excess will need to be dissipated as heat through the regulator.

  LEI 21538 PDF

This site uses Akismet to reduce spam.

Basic to use LM We love it because easy to use. A programmable output regulator. However, other values such as or ohms can also be used for R 1. The LM voltage regulators can provide up to 1. A precision current regulator.

LM317 / LM338 / LM350 Voltage Regulator Calculator

For example A simple adjustable switching regulator. Also, its pin output connects the heatsink surface. We can use the LM on a wide variety of applications. It looks much like the popular LM The adjustment terminal of the regulator can be bypassed to achieve very high ripple rejection. No protection diodes are required for output dqtasheet of less than 25V or greater than 10 uF capacitance. Created 28 July If you want to try it.

Which it looks like a popular LM Please update your bookmarks. But It can supply the output current over 3. You see LM circuit below. The dropout voltage of the IC regulator is about 1.

  GYRODYNAMICS AND ITS ENGINEERING APPLICATIONS PDF

If you are looking for 3A adjustable power supply. This is an LM Datasheet. Because you like many circuits to make on your working. When external capacitors are used with a voltage regulator it may be necessary to use protection diodes to prevent the capacitors from discharging through low current points into the voltage regulator.

LM Datasheet(PDF) – Motorola, Inc

To datasyeet the output voltage, enter values for the program R 1 and set R 2 resistors and hit the “Calculate” button. You can buy at mouser. We use only 2 resistors to control the output voltage. Even small capacitors can have a low enough internal series resistance to be able to deliver 20A spikes when shorted.

See the voltage regulator datasheets above for specific details regarding the dropout voltage and heatsink requirements.
