This project has been design around HT12E and HT12D encoder / decoder chips from Holtek. With jumper selectable address on the receiver. The HT12E Encoder ICs are series of CMOS LSIs for Remote Control system applications. They are capable of Encoding 12 bit of information which consists of 8. Robokits India HT12E & HT12D Encoder and Decoder IC for RF Modules [RKI- ] – The HT 12E Encoder ICs are series of CMOS LSIs for Remote Control.
